Large Industrial Spray Booths
Workpiece envelope, access and air movement determine the booth size and layout.
JI HENG TECHNOLOGY
Industrial Spray Booths & Custom Heavy-Duty Finishing Enclosures
Large, heavy-duty and custom-size spray booths engineered for real production environments.
Custom DesignAutomated / ManualProject-Specific EnergyTurnkey Project
Request a Custom Solution
From Our Product Catalog
Documented equipment and process scope
The catalog shows both mobile telescopic spray booths and non-standard spray rooms in multiple sizes and layouts. It discusses airflow, temperature, humidity and cleanliness as design considerations for painting operations.
Explosion-protected components and hazardous-area suitability must be specified and verified for each project; the catalog does not certify every booth as explosion-proof.
Equipment shown or described
- ✓Mobile telescopic booths
- ✓Fixed custom spray rooms
- ✓Dry or wet booth concepts
- ✓Air supply and extraction
- ✓Filtration and lighting
Source: JI HENG TECHNOLOGY product catalog, PDF pages 6–10.
View English product overview (PDF) →Spray Booth Configurations
Industrial spray booths built to the workpiece and site
As an industrial spray booth manufacturer in China, JI HENG TECHNOLOGY develops custom-engineered booths from the workpiece dimensions, application process, airflow, filtration and plant layout. The same engineering process supports tailored, non-standard and custom-size requests.
Heavy-Duty Spray Booths
Large or heavy parts may require reinforced handling, floor access and project-specific ventilation design.
Custom-Size Spray Booths
Dimensions and room arrangement are tailored to the workpiece, plant space and operating method.
Retractable Spray Booths
Mobile telescopic booths are documented in the company catalog and can be considered where the production layout requires flexibility.
Explosion-protected configuration
If a project requires an explosion-protected spray booth, the hazardous-area classification, electrical components, ventilation, grounding and applicable standards must be specified in its technical agreement. General spray booth photographs do not establish an explosion-proof rating.
Looking for a custom spray booth supplier or factory? Send the workpiece drawing and planned process for a project-specific proposal.
Core Subsystems
Inside the complete system
These are the engineering modules to review for this type of system. Final configuration follows the approved project scope.
Booth Enclosure
Custom wall, roof and access construction sized around the maximum workpiece envelope.
Air Supply System
Filtered make-up air and distribution designed for the required operating condition.
Exhaust & Filtration
Dry or wet filtration and extraction arranged around the application process.
Lighting & Visibility
Integrated illumination planned for inspection and safe production operation.
Controls & Interlocks
Fan, alarm and process controls are coordinated under the approved electrical design.
Retractable or Fixed Structure
Fixed, telescopic or custom heavy-duty concepts are available after engineering review.
Project-Specific Parameters
Configured by technical agreement
These are design inputs, not a fixed model specification. No standard dimensions, capacities or performance figures are asserted without a confirmed project drawing and calculation.
| Workpiece envelope | Confirmed from maximum part dimensions, clearance and access needs |
|---|---|
| Booth layout | Fixed, retractable or other project-approved arrangement |
| Airflow and filtration | Calculated from paint process, booth geometry and local requirements |
| Electrical and safety design | Specified against the destination site's hazard assessment and applicable rules |
| Utilities and controls | Agreed for the available site supply and operating method |
The customer and engineering team confirm the destination country, installation site, applicable laws and standards, technical parameters and acceptance criteria in the signed project documents. Custom design does not by itself establish certification or legal compliance.
Applicable Workpieces
Designed around the product
Discuss the workpiece, substrate and finish with our team. These application areas are planning examples; the gallery photos may show other configurations.
Large machinery
Vehicle components
Metal fabrication
Custom workpieces
Product Gallery
More views of this equipment series
Selected photos from the supplied product image library. These views may represent different projects and configurations.
Related Equipment References
See more documented views before requesting a design
These classified equipment photographs come from the supplied image library. Customer identity, installation date and process settings are not yet verified as case-study data.
Technical Evaluation
Request Engineering ScopeBring your requirements to our engineering team
Request a project-specific layout and engineering scope for internal evaluation.
Planning a custom spray booth?
Send us your workpiece or process details, production target and factory layout for an application-specific proposal.
